JCB3-125DC DC circuit breaker
TECHNICAL DATA
JCB3-125DC DC circuit breaker specifications
W9 Group lists the JCB3-125DC DC circuit breaker for overload and short-circuit protection in direct-current circuits. The summary identifies a high-current range and pole-dependent voltage capability; confirm the exact ordered configuration and wiring before selection.
| Model | JCB3-125DC |
|---|---|
| Product category | DC miniature circuit breaker |
| Listed current limit | Up to 125A |
| Pole options | 1 pole, 2 pole, 3 pole, 4 pole |
| Summary voltage scope | Up to 1000V DC; four-pole configuration stated |
| Listed breaking capacity | 10kA; confirm operating conditions |
SELECTION GUIDE
JCB3-125DC high current DC MCB selection
Specify the complete order code, circuit duty, installation conditions and required documents when requesting a JCB3-125DC quotation from W9 Group.
Define the supply circuit
Provide the supply type, maximum circuit voltage and earthing arrangement. Confirm the required pole connection from the matching wiring diagram.
Coordinate current and release
Choose the ordered current using conductor and load duty. Request the exact trip curve and any installation-related derating.
Compare fault interruption
Provide the prospective short-circuit current. Confirm the breaking rating, operating voltage and applicable test standard together.
Check installation details
Request terminal limits, mounting dimensions, torque and accessory compatibility for the complete model code.
ABOUT W9 GROUP
W9 Group support for JCB3-125DC DC MCB
Zhejiang W9 Group Technology Co., Ltd. supplies low-voltage electrical products. For a JCB3-125DC enquiry, contact W9 Group about configuration and matching product documents.
RELATED RESOURCES
JCB3-125DC DC MCB Connection Diagrams
Use technical support and related products to specify JCB3-125DC. Request a datasheet and wiring diagram matching the selected JCB3-125DC configuration.
RELATED PRODUCTJC3BE-DCCompare function and configuration; request separate model ratings
DOCUMENTSW9 Group download centreRequest the current document for your quoted JCB3-125DC variant
BUYER FAQ
JCB3-125DC DC MCB selection FAQs
Find answers about JCB3-125DC selection, configuration and ordering.
Does the maximum DC voltage apply to one pole?
No. The summary states up to 250V DC per pole and identifies the four-pole version for up to 1000V DC. Confirm the exact diagram and voltage for the ordered pole arrangement.
Which currents can I order?
The summary lists currents up to 125A. Request the complete current-option schedule and matching trip curve; the maximum is not a statement that every unit has the same current.
Is the breaker non-polarity?
A non-polarity connection is not established by the available target summary. Confirm terminal polarity and permitted current direction from the exact wiring diagram.
How should I verify the breaking rating?
The supplier lists 10kA. Confirm its DC operating voltage, pole connection and test conditions before comparing it with the prospective fault current.
Can an AC-rated breaker be substituted?
Confirm a dedicated DC rating and connection arrangement. AC ratings alone do not establish suitability for interrupting a direct-current fault.
What installation details should be requested?
Request dimensions, terminal conductor limits, tightening torque, enclosure requirements and any DC-specific connection instructions for the selected version.
What is needed for a JCB3-125DC quotation?
Send the required configuration, quantity, destination market and document requirements. Ask W9 Group to confirm price, minimum order quantity, samples and lead time for the selected configuration.
PRODUCT ENQUIRY
Request a JCB3-125DC DC circuit breaker quotation
Tell W9 Group your complete order code, circuit duty, installation conditions and required documents, quantity and destination market so the selected configuration can be identified.
