Manija giratoria de la MCCB ERH-M6
DATOS TÉCNICOS
ERH-M6 MCCB rotary handle specifications
The ERH-M6 MCCB rotary handle is listed for the W800/1000 frame designation. It operates a compatible breaker through a mechanical transmission. Confirm the frame, door geometry and shaft or linkage dimensions before preparing the panel.
| Marco | 63/125 | 160 | 250 | 400/630 | W630/800 | W800/1000 |
| Code | M1 | M2 | M3 | M4 | M5 | M6 |
| Shell frame current | 63A/125A | 160A | 250A | 400A/630A | W630A/800A | W800A/1000A |
| Installation size H (mm) | 53.5 | 61.5 | 63.5 | 98 | 97 | 97 |
| The handle size L (mm) | 65 | 95 | ||||
