لوازم جانبی MCCB: با ولتاژ پایین، اتصال AC230V، AC380V، DC240V، DC 24V، با سیم کشی یا ترمیال
اطلاعات فنی
MCCB Undervoltage Release and Coil-Supply Information
W9 Group lists an MCCB undervoltage accessory with wiring or terminal connections and AC230V, AC380V, DC240V and DC24V designations in the title. Specify the host breaker and exact control supply, then confirm the coil version and operating sequence for the quoted accessory.
The title voltage options and retained original electrical table are not identical. Confirm one exact AC or DC coil voltage on the nameplate and matching wiring diagram before energizing the accessory.
| بُعد | 125/160 | 250 | 400 |
| کد | UVT-125 | UVT-250 | UVT-400 |
| UE(V) | AC | دی سی | |||
| 230 ولت | ۴۰۰ ولت | 110 | 220 | 24 | |
| ln(A) | 0.3 | 0.3 | 0.15 | 0.15 | 0.15 |
راهنمای انتخاب
Selecting MCCB undervoltage release with wiring or terminals for Your Installation
Use MCCB undervoltage release as the enquiry reference and confirm the selected configuration against your circuit, connection and installation requirements.
شناسایی قطع کننده اصلی
Provide the full MCCB model, frame and existing accessory arrangement. Confirm mechanical and electrical compatibility before ordering.
Specify the required function
Describe the operating or signaling task and the intended control system. Confirm the accessory function and any additional components.
Match the connection details
Request the exact wiring or installation drawing, mounting dimensions and terminal arrangement for the offered accessory.
Confirm the order contents
Confirm included parts, operating conditions and required documentation. Do not infer a complete control assembly from an accessory name.
